2-positions 10-port injection valve bank(HPLC)

PRODUCTS > Two-position injection valve > 2-positions 10-port injection valve bank(HPLC)

2-positions 10-port injection valve bank(HPLC)

    • 1
Two-positions 10-port high-pressure injection valve is self-developed, independently-manufactured, highly precise and reliable.
• High precision and reliability
• Maximum pressure can reach 40 MPa (liquid)
• Liquid temperature 5~150℃
• Valve core material PEEK
• Valve material (SUS316L、N60、hastelloy)
• Mode of drive: electricity-driven or air-driven
• Standard configuration RS232/RS485 communication interface
• Passivation of valve surface (optional)

Application
The valve bank is extensively applied in liquid chromatography instruments, solvent extractors and other laboratory analysis instruments, and it can replace valve banks imported overseas.
流道孔径0.1mm、0.3mm、0.4mm、0.5mm、0.6mm
接口规格10-32UNF内螺纹
转子材质PEEK
阀体材质SUS316L、Nitronic 60、哈氏合金
端口到端口容积0.22~1.07uL
最大耐压气体：15MPa；液体：40MPa
过液温度0~150℃
最大驱动力≤2.5N/m
驱动方式电动、气动（正常驱动压力为0.45MPa）
通讯接口RS232/RS485（波特率：19200bps）、I/O （适用于电动驱动）
工作电压24VDC/1.5A
最大功率36W
工作环境温度0~50℃
工作环境湿度≤80%RH无冷凝状态
